Project Aura

Support this project: back the crowdfunding to get detailed build instructions, 3D-printable enclosure models, and wiring guides at: https://makerworld.com/en/crowdfunding/159-project-aura-make-the-invisible-visible

Project Aura is an open-source ESP32-S3 air-quality station built for makers who want a polished, reliable device rather than a bare sensor board. It combines a touch-friendly LVGL UI, a local web setup portal, and MQTT with Home Assistant discovery.

This repository contains the firmware source code and configuration needed to flash and customize the device.

Join the community: GitHub Discussions

Table of Contents

• Video Demo
• Highlights
• Gallery
• UI Screens
• Hardware and BOM
• Assembly and Wiring Notice
• Pin Configuration
• UI Languages
• Firmware Architecture
• Build and Flash
• Configuration
• MQTT + Home Assistant
• Contributing
• License and Commercial Use
• Tests
• Repo Layout

Video Demo

Click the image.

Highlights

• Professional telemetry: PM2.5/PM10, CO2, VOC, NOx, temperature, humidity, absolute humidity (AH), pressure, HCHO.
• No soldering required: designed for easy assembly using Grove/QT connectors.
• Smooth LVGL UI with night mode, custom themes, and status indicators.
• Easy setup: Wi-Fi AP onboarding + mDNS portal (http://aura.local) for configuration.
• Home Assistant ready: automatic MQTT discovery and ready-to-use dashboard code.
• Robust Safe Boot: automatic rollback to the last-known-good config after crashes.

Gallery

UI Screens

Dashboard	Settings	Theme Presets
MQTT	Date & Time	Backlight

Hardware and BOM

Project Aura is designed around high-quality components to ensure accuracy. If you are sourcing parts yourself, look for these specific modules:

Component	Part / Model
Core Board	Waveshare ESP32-S3-Touch-LCD-4.3 (800x480)
Main Sensor	Sensirion SEN66 (via Adafruit breakout)
Formaldehyde	Sensirion SFA30 (Grove interface, optional)
Pressure	Adafruit BMP580 or DPS310
RTC	Adafruit PCF8523

Sensor note: the SFA30 is fully supported and widely available. Support for the successor model (SFA40) is on the roadmap. Note: SEN66 gas indices (VOC/NOx) require about 5 minutes of warmup for reliable readings; the UI shows WARMUP during this period.

Recommended retailers: Mouser, DigiKey, LCSC, Adafruit, Seeed Studio, Waveshare.

Assembly and Wiring Notice

Please pay close attention to the cabling. The pin order on the board is custom and requires modification of standard off-the-shelf cables (pin swapping).

Backers: please refer to the comprehensive Build Guide included in your reward for the exact wiring diagram and a trouble-free assembly.

DIY: verify pinouts against the pin table below before powering on to avoid damaging components.

Pin Configuration

Component	Pin (ESP32-S3)	Notes
3V3	3V3	Power for external I2C sensors
GND	GND	Common ground
I2C SDA	GPIO 8	SEN66, SFA30, BMP580 (external)
I2C SCL	GPIO 9	Shared bus

Display and touch are integrated on the board; no external wiring is needed for them.

UI Languages

Project Aura speaks your language. You can switch languages in the Settings menu:

• English
• Deutsch
• Espanol
• Francais
• Italiano
• Portugues BR
• Nederlands
• Simplified Chinese

Firmware Architecture

Data flow and responsibilities are intentionally split into small managers:

graph TD
    subgraph Hardware
        Sensors[Sensors<br/>SEN66, SFA30, BMP580]
        Touch[Touch<br/>GT911]
        RTC[RTC<br/>PCF8523]
        LCD[LCD + Backlight]
    end

    subgraph Core
        SM[SensorManager]
        NM[NetworkManager]
        MM[MqttManager]
        TM[TimeManager]
        CoreLogic[BootPolicy / Watchdog / MemoryMonitor]
    end

    subgraph Data
        History[PressureHistory]
        Storage[(LittleFS<br/>config/last_good/voc/pressure)]
    end

    subgraph UI
        LVGL[LVGL UI]
        Web[Web Config Portal]
    end

    Sensors -->|I2C| SM
    RTC -->|I2C| TM
    Touch -->|I2C| LVGL
    LCD --> LVGL
    SM -->|Data| LVGL
    SM -->|Data| History
    History <-->|save/load| Storage
    Storage <-->|config| NM
    Storage <-->|config| MM
    NM --> Web
    NM --> MM
    MM -->|Publish| HA[Home Assistant]

    style CoreLogic fill:#f96,stroke:#333,stroke-width:2px

Loading

Core modules live in src/core/ and orchestrate startup (AppInit, BoardInit). Feature managers are in src/modules/, UI in src/ui/, and web pages in src/web/.

Build and Flash (PlatformIO)

Prerequisites: PlatformIO CLI or VSCode + PlatformIO extension. Built with Arduino ESP32 core 3.1.1 (ESP-IDF 5.3.x).

git clone https://github.com/21cncstudio/project_aura.git
cd project_aura
pio run -e project_aura
pio run -e project_aura -t upload
pio run -e project_aura -t uploadfs
pio device monitor -b 115200

Configuration

1. Wi-Fi setup: On first boot, the device creates a hotspot: ProjectAura-Setup. Connect to it and open http://192.168.4.1 to configure Wi-Fi credentials.
2. Web portal: Once connected to your network, access the device at http://aura.local/. Configure MQTT, timezone, and themes there.
3. Home Assistant: MQTT discovery is enabled by default. The device appears in HA via MQTT integration automatically. A ready-to-use dashboard YAML is available at docs/home_assistant/dashboard.yaml. Setup guide: docs/home_assistant/README.md.

Optional compile-time defaults belong in include/secrets.h, which is ignored by git. Copy and edit:

copy include/secrets.h.example include/secrets.h

MQTT + Home Assistant

• State topic: <base>/state
• Availability topic: <base>/status
• Commands: <base>/command/* (night_mode, alert_blink, backlight, restart)
• Home Assistant discovery: homeassistant/*/config

MQTT stays idle until configured and enabled.

Contributing

Contributions are welcome! Please read CONTRIBUTING.md for details on the process for submitting pull requests and the Contributor License Agreement (CLA).

Found a bug? Open an Issue: https://github.com/21cncstudio/project_aura/issues Have a question? Ask in Discussions: https://github.com/21cncstudio/project_aura/discussions

License and Commercial Use

• Firmware in this repository is licensed under GPL-3.0-or-later (see LICENSE).
• Commercial use is allowed under GPL. If you distribute firmware (including in devices), you must provide the Corresponding Source under GPL.
• If you need to sell devices while keeping firmware modifications proprietary, obtain a Commercial License (see COMMERCIAL_LICENSE_SUMMARY.md).
• Enclosure models and the PDF build guide are not in this repository; they are available to backers on MakerWorld under separate terms.
• Trademark and branding use is covered by TRADEMARKS.md.

Tests

See TESTING.md for native host tests and scripts/run_tests.ps1.

Repo Layout

• src/core/ boot, init, reliability
• src/modules/ sensors, storage, network, MQTT, time
• src/ui/ LVGL screens, assets, controllers
• src/web/ HTML templates and handlers
• test/ native tests and mocks
